| Absolute ratingSupply voltage(±Vs)± 16.5VSignal input voltageDifferential inputCommon input ± 1V, ±0.7V (at power off)±Vs,±0.7V (at power off)Offset input voltage± VsInputInput typeDC coupling, Balanced differential inputDifferential input impedance100k ohm (typ) within 5%@DC(single ended)Parallel capacitance 80pF(typ)Common input impedance500k ohm;(typ) @DCParallel capacitance 130pF(typ)Linear max. differential input voltage±100mV @1kHzLinear max. common input voltage±10V @1kHzInput bias current±30nA(typ)Input offset current±7nA(typ)CMRR(input referred)100dB or greater 120dB(typ)@60HzInput referred noise voltage density1.8nV/√Hz or less @1kHz (inputshort circuit)1.5nV/ √Hz (typ) @1kHz(input short circuit) |
