| Sensitivity100nV to 1V fullscale, in 1-3 steps(10nV at the METER MAG operation)Frequency range0.5Hz to 200kHzInput typeDifferentialInput impedence10M // 40pFCommon-mode rejection ratio110dB or greater(at 1 kHz)Input referred noise5nV /√Hz or lower(at 1 kHz)FilterLPF, HPF, BPF, automatic tuning is available.Reference signal modeEXT F/2F, INT F/2FInternal oscillator0.5Hz to 120kHzMeasurement displayDATA1 : One of either A, A(dB), A% X(Acosφ), X(dB), X(%) DATA2 : One of either φ or Y (Asin φ)DATA3 : One of either ratio,reference frequency, EXT DCMonitoring meterAcosφ and AsinφTime constant1ms to 30s, 6dB/oct or 12dB/octAveraging functionsLinear or exponential averaging modeNo. of averages : 21 to 29InterfaceGPIB, RS-232CPower requirementsAC100, 120, 220 or 240V switchableDimensions(mm)432(W) X 132.5(H) X 500(D)Weightapprox.13.5kg |
二維碼
Computer interface(GPIB, RS232C)
